Power Supply Information
Models STAREX004W-64 or STAREX008W-64
iSTAR eX ships with a PMB (Power Management Board), which is mounted
inside the iSTAR eX enclosure. The iSTAR eX GCM gets power from the PMB
and communicates with the PMB over a Serial Peripheral Interface (SPI) bus.
The PMB is connected to the UL Recognized ESD, Model SPS-6.5, and to a
12 VDC, 17.2 Ah minimum capacity standby battery. The PMB charges
the battery, detects power loss, restores main power, and manages
switching between main and battery power.
The iSTAR eX GCM, PMB, ESD Power Supply, and Battery connections are
factory-installed in the enclosure. iSTAR eX and its peripherals can remain
fully operational after losing main power.
Models STAREX004W-64NB or STAREX008W-64NB (No Battery)
Include a 17.2 - 18.0 Ah battery to provide at least 4 hours standby power.
Connect the battery as shown in Figure 1.9 on page 1-19.
Models STAREX004W-64NPS or STAREX008W-64NPS (No Power
Supply or Battery)
In order to maintain a UL Listing, the system must be powered by a UL 603
Listed, power limited power supply with appropriate ratings and a minimum
4 hours of standby power, such as the Software House apS. Connect the
power outputs, AC Fail and Low battery connections as shown in Figure 1-2
on page 1-7.
Do not use the iSTAR eX GCM without the PMB board. The PMB board
provides backup and power management.
NOTE
STAREX004W-64NB and STAREX008W-64NB have not been evaluated by
UL.
