STAR eX Diagnostic Tests
iSTAR eX Installation and Configuration Guide 7–9
Table 7-8: Rotary Switch SW1 Diagnostic Tests for iSTAR eX
Set SW1 to Performs this Action Notes
F
Displays general status messages.
ICU fields are Read Only and cannot be changed.
ICU Block on
0
Displays general status messages. Users can Read, Write,
and Update ICU configuration.
ICU Block off
1
Displays most recent card swipe for 1 second Fast Mode on
2
Displays most recent card swipe for 7 seconds Slow Mode on
3
Tests and displays information about manual inputs for 1
second
Slow Mode Input Test
4
Tests and displays information about manual inputs for 2
seconds
Fast Mode Input Test
5
Activates output change display tests for manually
activated outputs and displays information for 2 seconds
Slow Mode Output Test
6
Activates and tests all onboard outputs and other
outputs attached to an iSTAR eX through readers and R/8
boards for 1 second
Fast Mode Output test.
LCD does not display all info
7
Activates and tests all onboard outputs only on an iSTAR
eX, one by one. Test results are indicated by the LED
associated with each output.
Displays results on LED
8
Tests and displays diagnostic information about Ethernet #1
and Ethernet #2 ports.
Ethernet Port and CF Slot
Te s t
