D–2
iST
AR eX Installation and Configuration Guide
iST
AR eX Wire Routing Diagrams
Figures in this appendix illustrate the Class 2 wire routing with
in the
enclosure for inputs, relay outputs and readers.
NOTE
There must be a minimum of 1/4”
separation between Class 2 power
limited wiring and Cl
ass 1
non-power limited wiring.
WARNING: For Continued Protection Ag
ainst the Risk of Fire, Replace
Only with Same Type and Rati
ng of Fuse. 10 Amp, 250 VAC
217
219
Table of Contents
Default Chapter
3
Table of Contents
3
How to Use this Manual
14
Preface
14
Conventions
15
FCC Class a Digital Device Limitations
16
Canadian Radio Emissions Requirements
17
FCC Class B Notes
17
CE Compliance
18
Important Safety Information
18
Power Supply Information
19
Product Information
20
Chapter 1 Introducing Istar Ex
22
Istar Ex Features
22
Memory
22
Cluster Configuration
22
Events
22
System Activity
23
Antipassback Control
23
Diagnostic Information
23
Upgrading Firmware
23
C•CURE Integration
24
Compatibility
24
System Components
25
Istar Ex General Controller Module (GCM)
28
GCM Features
28
GCM Component Layout
30
Istar Ex GCM Component Description
31
Istar Ex GCM Leds
32
Power Management Board (PMB)
33
PMB Features
33
PMB Component Layout
34
PMB Component Description
35
Star Coupler Feature
36
Istar Ex GCM - PMB Interconnections
37
SPI (Serial Peripheral Interface) Connection
38
PMB - Power Supply - Battery Interconnections
39
Istar Ex Capacities
40
Gcm
40
Pmb
40
Input/Output Capacities
40
Optional Hardware Modules
42
Istar Ex Connections
43
Inputs
43
Outputs
44
Readers
44
Istar Ex Tools
45
Icu
45
Configuring Controllers
46
Viewing Controller Status
46
Istar Web-Based Diagnostic Utility
46
Power System
47
Power Supply
48
Power Supply/Battery Switch-Over Circuitry
48
Battery Charger Circuitry
48
Alarms, Leds, and Battery (Standard Model with Power Supply and Battery)
48
Power Failure Alarm
48
Battery Low Alarm
48
Power-On LED Indicator
49
Battery Charging LED
49
Heartbeat LED
49
Standby Battery
49
Battery Operating and Charging Time
49
Alarms, Leds, and Battery (Model NPS)
49
Power Failure Alarm
50
Battery Low Alarm
50
Power-On LED Indicator
50
Heartbeat LED
50
Backup and Restore
51
State and Configuration Backups
51
Event Triggered Backup
52
Istar Ex Backup and Real Time Clock
52
Istar Ex Power Failure Signals
52
Standard Model with Power Supply and Battery
52
Istar Ex Power Failure Signals
53
Model NPS
53
Pmb
54
Istar Ex Power Fail Detection and Backup Logic
56
AC Fail
56
Low Battery
56
Backup Now (Standard Version Only)
56
Backup Restore Process
57
Preventing Restarts Without Power
57
Restore
57
Chapter 2 Istar Ex Topology
60
Istar Ex Network Topology
60
Lan and Wan Configurations
60
Gateways and Firewalls
60
Local Address Management
61
IP Management Tools
62
Using Netbios and Fully Qualified Domain Names
63
Cluster Configuration
64
Master and Member Configuration
64
Single Master and Alternate Master Configurations
65
Single Master Configurations
66
Alternate Master Configurations
66
Primary Communications Path
67
Secondary Communications Path
68
Maintaining Cluster Communication
69
Single Master Configurations
69
Alternate Master Configuration
70
Communication between Members and Master
71
Adding Controllers to the Cluster
72
Configuring Communication Paths
73
Planning Primary Communications
73
Primary Communication Guidelines
73
Planning Secondary Communications
74
Chapter 3 Site Requirements
75
Pre-Installation Planning
76
Equipment Check
76
Site Check
76
Voltage Requirements and Distance
77
Installation Tools
77
Installation Requirements
78
Host System Requirements
78
Istar Ex Cabinet Requirements
78
Environmental Requirements
78
Power Requirements (Standard Power Supply and NPS Models)
79
Istar Ex Components and Boards
79
Istar Ex Input Power Rating
80
Individual/Total Loads Evaluated by UL
80
Istar Ex GCM Wiegand Reader Ports
81
Software House Readers
82
Third Party Readers
83
Wyreless Products
83
Ethernet Requirements
84
Wiring Requirements
84
Grounding Requirements
86
Chapter 4 Hardware Installation
88
Installation Overview
88
Installation Procedure
88
Mounting the Enclosure
89
Static Electricity
89
Connecting to the Host
93
Primary and Secondary Connections
93
Connecting to the Host Via the Network
93
To Connect to a 10/100Base-T Network
93
Low Battery, AC Power Fail, and Tamper Inputs
95
Tamper
95
Low Battery and AC Power Fail (Standard Power Supply Model)
95
Low Battery and AC Power Fail (NPS Model)
95
Connecting AC Power to UL Recognized ESD Power Supply
98
ESD Power Supply
98
Grounding Procedure
99
Istar Ex Power Supply Layout - Standard and NPS Versions
99
Standard Version Power Supply Layout
99
NPS Version Layout (External Power Supply)
99
Istar Ex UL System Configuration
102
Standard or NPS Version (External Power)
102
Istar Ex Connections
103
Wiring RM and Wyreless Readers, I/8S and R/8S to PMB
104
PMB Connections
105
Wiring RM Devices to PMB
107
Wiring Wyreless Pims to the PMB
107
Istar Ex PMB - Wyreless Pinouts
108
Wiring Inputs and Outputs to the GCM
109
Wiring NC and no Double Inputs
110
Wiring NC and no Single Inputs
110
Wiring Non-Supervised Inputs
111
Wiring Double Inputs Using Common
111
Wiring Relay Outputs to Istar Ex GCM
112
Wiring Open Collectors to Istar Ex GCM
113
Wiring Collector Outputs Using Internal Supply
113
Wiring Collector Outputs Using External Supply
114
Wiring Wiegand Readers to Istar Ex GCM
114
Wiring Direct Wiegand Readers
114
LED Connections
115
LED Control
115
External Bi-Color LED Control
116
Wire (Red and Green)
116
Wire (Yellow)
117
Wire (Red, Green, Yellow)
118
One Wire ABC LED Control
119
One Wire (A, B, C)
119
NPS Version (External Power Supply)
120
Istar Ex - Support for Istar Ex 8 Reader Option
122
Normal Istar Ex Operation - Supports 4 Readers
122
Optional Istar Ex Configuration - Supports 8 Readers
122
Configuring an Istar Ex Controller for 8 Readers
124
Using the USB Security Key to Enable Readers 5-8
125
Monitoring Station
128
Journal Reports
130
ICU Configuration Screen Status
131
Istar Web Page Diagnostic Utility
133
Exporting Custom Certificates with the 8 Reader Option
134
Chapter 5 Using the Istar Configuration Utility (ICU)
136
Overview
136
Configuring a Master Controller
137
Troubleshooting Tools
137
C•CURE 800/8000 Configuration Diagnostics
137
General Configuration Procedure
138
LAN Configurations
138
WAN Configurations
139
Copying the ICU Onto a PC or Laptop
142
Understanding the ICU
143
Displaying and Updating Cluster Information
143
ICU Block Feature
144
Starting the ICU
145
Refreshing Controller Information
147
Setting ICU Options
147
Setting a Refresh Interval
148
Changing the ICU Password
149
Setting the Public IP Address for Firmware Downloads
149
Setting the TCP/IP Port for Firmware Downloads
149
Using the ICU Window
150
The Toolbar
150
Icons
151
Display Area
153
Menu Bar
155
Status Bar
155
Configuring a Controller
156
Prerequisite Information
156
Configuring SNMP
163
Digital Certificate Signing and Restore Options
167
Connecting to the Istar Web Page Diagnostic Utility
169
Disabling Web Diagnostics
172
Sending Messages to Other ICU Users
173
Downloading Firmware Updates
174
Chapter 6 Istar Web Page Diagnostic Utility
178
Starting the Diagnostic Utility
178
Navigating the Diagnostic Utility
179
Viewing the Status Screen
180
Viewing the Cluster Information Screen
183
Viewing the Object Store Database Screen
184
Diagnostic Screens
186
Network Diagnostics
186
Reader and I/O Diagnostics
187
SID Diagnostic Levels
188
Displaying Diagnostic Information
188
Chapter 7 Using the LCD Diagnostic Display
191
Setting the LCD Message Display
192
Displaying Status Messages
193
Setting LCD Status Message Display
193
Istar Ex Diagnostic Tests
194
Card Reader Diagnostics
194
Output Diagnostics
195
Output Change Display (Slow Mode)
195
Output Change Display (Fast Mode)
195
Output Test Mode
196
Input Change Display Mode
196
Port and CF Slot Test
197
STAR Ex Diagnostic Tests
198
Controls and Indicators
201
Appendix A Controls and Indicators
202
Istar Ex GCM Controls and Indicators
202
Istar Ex GCM Leds
203
Diagnostic and Status Messages
204
PMB Controls and Indicators
205
LED Control
206
External Bi-Color LED Control
206
Wire (Red and Green
207
Wire (Yellow
208
Wire (Red, Green, Yellow
209
One Wire (A, B, C
210
Istar Ex PMB - Wyreless Pinouts
211
Appendix B Part Numbers
213
Istar Ex Part Numbers
214
Appendix C Maintenance
215
Maintenance and Diagnostic Schedule
216
Lead Acid Battery Replacement / Maintenance - Yearly
216
Lithium Battery Replacement - as Needed
216
Fuse Replacement - as Needed
216
Diagnostic Tests - as Needed
216
