Mounting th
e Enclosure
4–4
iST
AR eX Installation and Configuration Guide
Figure 4.1:
S
tandard Controller Mountin
g
7.
Remove the appropriate knockouts fo
r wiring the inputs and outputs.
8.
Attach conduit couplings to the knockout openings as needed to comply
with code.
Mounting
keyhole slots
Bottom
mounting holes
14-1/4“
22-1/4“
89
91
