Ultrasonix SonixTablet - Chapter 2: System Specifications; Dimensions; Electrical Ratings; Voltage Adjustment

SonixTablet Service Manual 00.053.129, Revision C Chapter 2: System Specifications
2-1
CHAPTER 2: SYSTEM SPECIFICATIONS
2.1 DIMENSIONS
Table 2-1: System Dimensions
2.2 ELECTRICAL RATINGS
Table 2-2: Electrical Ratings
Table 2-3: Fuses, Two (2) Required
2.3 VOLTAGE ADJUSTMENT
The standard Voltage Rating for North America is 110 – 125V. The system is equipped to operate at 100 – 120V (±10%) and
200 – 240V (±10%).
Table 2-4: International Electrical Voltage Ratings
Measurement Metric Value US Value
Width 45 cm 17.7 in
Depth 17 cm 6.9 in
Height 41 cm 16.1 in
Weight 14.77 kg 32.5 lbs
Power Pack Size (W x L X H) 10.4 cm x 40 cm x 5.8 cm 4.1 in x 15.75 in x 2.3 in
Power Pack Weight 2.7 kg 6.95 lbs
Input
100V—120V @ 50/60 Hz
200V—240V @ 50/60 Hz
Power Rating
120 VAC @ 7.0A
240 VAC @ 4.0A
Fuse Type 7A/250V SLO-BLO
Fuse Size 6.4 mm x 31.8 mm
Note: Section 2.2 has details on electrical ratings and fuses. Table 2-4 lists international electrical voltage ratings. Refer to
sections 3.3.1.1 and 3.3.2.2 for instructions on configuring voltage and changing fuses.
Afghanistan...................................... 220V Granada .......................................... 220V Oman............................................... 220V
Algeria .......................................110/220V Greece............................................. 220V
Pakistan........................................220V
Angola ............................................. 220V Greenland........................................ 220V Panama ............................................110V
Antigua ............................................ 220V Guatemala........................................110V Paraguay ......................................... 220V
Argentina ......................................... 220V Guinea............................................. 220V Peru ...........................................110/220V
Aruba................................................110V Guyana .............................................110V Philippines .................................110/220V
Australia .......................................... 240V Haiti ..................................................110V Poland ............................................. 220V
Austria ............................................. 220V Honduras ..........................................110V Portugal .....................................110/220V
Azores .......................................110/220V Hong Kong ...................................... 220V Puerto Rico.......................................110V
