SonixTablet Service Manual 00.053.129, Revision C Chapter 9: Network Configuration
9-3
9.1.1 Ethernet (LAN) Network Configuration
Figure 9-2: Network Configuration (Hard-Wired)
To Configure an Ethernet (LAN) Connection (If Available):
1. Connect an RJ45 cable to the LAN port located on the Back Connectivity Panel.
2. Tap the touch screen button.
3. Select Administrator > Network > Internet Connection using LAN.
4. Under Online Support, ensure the Enabled checkbox has been selected.
5. Select TCP/IP Settingsā¦.
6. Under General, select Obtain an IP address automatically or Use the following IP address and enter the
assigned static IP address, Subnet mask, and Default gateway.
7. Select OK and exit the Menu system.
9.1.1.1 Ethernet (LAN) Communication Test
To Perform an Ethernet (LAN) Communication Test:
1. Tap the touch screen button.
2. Select Online Support. This should connect the system to an Ultrasonix Technical Support Representative.
Note: Do not select the Chat Support Enabled checkbox unless there is an Internet connection available.
Note: It may be necessary to restart in order for the changes to take affect.
Note: It may be necessary to restart in order for the changes to take affect.
