Chapter 8: DICOM 00.053.129, Revision C SonixTablet Service Manual
8-14
8.1.4 DICOM Worklist Settings
DICOM Worklist Settings offer advanced settings for configuring the DICOM Worklist SCU.
To Configure DICOM Worklist Settings:
1. Tap the touch screen button.
2. Select Administrator > DICOM > Worklist.
3. Create/select a Device Name. Edit the Application Entity (AE) settings for the selected Device.
4. Repeat step 3 as many times as required.
5. Configure the dialog as required.
The DICOM Worklist AE Configuration dialog enables configuration of AE properties.
Figure 8-12: DICOM Worklist Settings – AE Configuration
Table 8-11: DICOM Worklist Settings – AE Configuration
Devices
Use the Devices option to add as many DICOM Worklist Servers as required.
Name
Enter/select the Name of an AE Worklist Device and populate the three (3) AE fields: AE Title, IP
Address and Port.
Add Select to Add the new AE Worklist Device.
Delete Select to Delete the selected AE Worklist Device.
Test Select to send verification request to DICOM Worklist Device (ping to verify connection).
Settings... Not available in this release.
Application
Entity (AE)
Note: The data entered/edited for the next three (3) fields is specific to the selected Device Name.
AE Title AE Title of the Worklist SCP.
IP Address Unique identifier of Worklist SCP.
Port Listening Port of the Worklist SCP.
Insert (Symbol)
Enables the insertion of text symbol(s) not available on the keyboard (e.g., punctuation, symbols and
letters from other languages).
