Chapter 4: Performance Testing 00.053.129, Revision C SonixTablet Service Manual
4-2
Table 4-1: Console Operation
4.2 IMAGE TEST
To Conduct an Image Test:
1. Connect each of the different transducers available and tap the touch screen button, then .
2. Verify that the image scanned has all elements present. Note any black static line(s) that are visible on the
image.
3. If found, test with the other transducers to verify the non-visible element(s) is in the same location.
4. Try different transducer connectors to eliminate the possibility of a malfunctioning transducer.
4.3 REMOVABLE HARDWARE (IF APPLICABLE)
The system supports many different types of removable hardware other than what comes with the system as a default
package. The following comprises a list of the supported removable hardware:
• medical grade USB printer
• medical grade Footswitch
• barcode reader
• USB media (memory stick, external hard drive, etc.).
Console/Touch Screen Button/Dial Expected Response
Tap the touch screen button once.
The QSONIX page will appear on both the touch screen and the LCD display.
Note: Tap again to exit QSONIX.
Tap the touch screen
button, then , then
.
The LCD display will move to M-Mode imaging.
Tap the touch screen
button, then , then
. Tap the top of the Clarity button to
increase it or the bottom to decrease it
.
The Clarity reading on the LCD display will move through the available settings as the
dial is turned (Off, Low, Med, High and Max).
Tap the touch screen button.
The button will change from gray to blue and the touch screen will display CINE
options.
Note: Tap and look for the red Record button.
M
