Uson SPRINT LC - Flow Calibration

Page 144
FIGURE 79
Enter Prev Next Help
SPRINT LC SET-UP
Test Parameters
Units
Calibration
Serial Port
Enter Prev Next
EXIT CALIBRATION
ENTER CALIBRATION
STOP - WARNING YOR ARE ABOUT
TO CHANGE CALIBRATION
Revision Level: 3.XX
Serial Number: 12345-1S
Enter Prev Next
Exit
Pressure Calibration
Flow Calibration
Time Verification
Back Reg+ Reg- Inc Dec
Flow Calibration
Reading
Flow Sensor 10.02 sccm
Target 10.00 sccm
Pressure 1.523 psig
