Page 27
Optional Foot Switch
If the foot switch is to be used, plugh the connector into the jack labeled
FT SW on back of the tester. The foot switch performs the same action as
pressing the START switch on the front panel.
AC Power
Plug the AC power cord into the AC receptacle. After all air and electrical
connections are in place, power up Sprint LC with the power switch on the
back of the tester.
1 (top position) is on.
0 (bottom position) is off.
AC Power Line Conditioner Option
If the Sprint LC is used in close proximity to electrical
equipment that can induce electrical noise into AC
power lines, consider purchasing the optional AC Power
Line Conditioner to supply power to Sprint LC. This
reduces radio frequency noise and other unwanted
signals that can ride the AC power line.
U
SE
R
T
I
P
