Appendix G
Data Plotting
The Sprint LC tester described in this Appendix has the ability to
download pressure and flow values at a set interval. These data points can
be imported to a spreadsheet to create a pressure or flow plot over time.
The interval for the data points may be set per program in the Test
Parameters menu.
Plot Interval
The Sprint LC Test Parameter menu is modified to include a Plot Interval
line. It may be set to OFF or 0.1 through 1.0 second. At the end of the test
all of the stored values are reported through the serial port. The time
interval selected determines how many values are recorded. The Sprint LC
does not buffer the information so the RS-232 cable must be connected to
collect the information. See pages 70 and 72 for more information on the
cable connection.
Plot Interval Program line
FIGURE 97
Back Prev Next Inc Dec
PROGRAM 1
Test Type PD
Test Press. 14.999 psig
Press. Error .5 psig
Coupling GoTo
Plot Interval OFF
Test Params GoTo
Next Program 0
Appendix 19
