Page 69
Changing Units —Continued
Figure 32. Change units of
measure at any time without
making calculations or re-entering
data.
When setting flow time, only the
flow measurement is affected.
Timers (couple, fill, stab, test and
dump) remain in seconds.
Available Units
The units displayed here may not
match your tester. The available
units will reflect the tests that are
included in the Sprint LC. For
example, if Sprint LC does not
have a flow test then the flow units
will not be available.
When Sprint LC does not have a
flow test available it provides the
option to calculate a flow rate (cc
per minute) based on the volume
and the pressure decay rate.
See pages 50-51.
When the conversion is available,
the units menu has an option to set
the volume units to either cubic
centimeters (cc) or cubic inches.
FIGURE 32
Back Prev Next Inc Dec
ENGINEERING UNITS
Pressure psig
Flow Volume cc
Flow Time /min
Enter Prev Next Help
SPRINT LC SET-UP
Test Parameters
Units
Calibration
Serial Port
To Next Page
