Page 35
Units Menu
From the Units menu, change units of measure for pressure, flow, volume,
and flow time. For example, change from pounds per square inch (psig) to
millimeters of mercury (mmHg). Or, it is possible to change from standard
cubic centimeters per minute (sccm) to standard liters per hour (slh).
Calibration Menu
This menu allows changing the sensor linearization lookup tables. Enter
the calibration menu only if it is intended to change calibration data.
Qualified technicians who have the necessary calibration instruments
should be the ONLY people accessing this critical area.
Serial Port Menu
This is where to set criteria for RS-232 communications. It is possible to
set baud rate, number of data bits, and number of stop bits.
Information sent from the Sprint LC serial port:
f Cycle number from the tested box
f Program number
f Test type (pressure decay, occlusion, flow or burst.)
f Test value from the main digital readout
f Units of measure set for the test value
f Result at the end of test (P ERR, GROSS, LEAK, PASS, etc.)
