Page 48
Secondary Parameter Menus
A second (pop-up) menu containing additional setup parameters will
display when the “Test Params” line is highlighted and the GoTo keypad
(INCREMENT) is pressed. This menu is used to set additional timers, reject
levels, or special functions associated with each test type.
General test parameters are described in the Sprint LC Owner’s Guide.
{INSERT GRAPHIC HERE}
Figure 20
Fill Time
Amount of time the part is allowed to fill with air pressure before Sprint
LC enters stabilization phase.
Back Prev Next Inc Dec
PROGRAM 1
Test Type Flow
Test Press. 10.000 psig
Press. Error .5 psig
Coupling GoTo
Test Params GoTo
Next Program 0
PRESSURE DECAY TEST
Fill Time 2.0 sec
Stab Time 1.0 sec
Test Time 3.0 sec
Dump AUTO
Rej Level .050 psig
Product Vol. 1.0 cc
.51 ccm
To Next Page
