Page 17
Key Commands
Re-Test
If Sprint LC says there’s a product failure, operators can re-test the
product by pressing the INCREMENT keypad. Re-test works only if the last
test failed. Operators can’t re-test a part that has passed. If the operator re-
tests a failed product, the tested counter does not advance. Sprint LC
counts only once for each test to keep an accurate log of the total number
of products tested.
Run Mode Functions
From the run mode, access the Run Mode Functions menu. Enter the run
mode function menu by pressing the ENTER/BACK keypad. This menu
allows the operator to change the current program, print a program header,
print a test summary or clear the counters.
See page 29
Abort
Press the START switch during the test, and ABORT pops up in the run
display status box show the process has stopped. Aborted tests don’t
register on the tested or reject counters.
Linked Programs
To get a pass light, the product being tested needs to stay inside all
established tolerances. If multiple programs are linked, the product must
stay inside tolerances for every program in the linked series.
Stop at First Failure
The fail light turns on at the first out-of-tolerance
condition and stops all tests. For example, Sprint LC does
not run program-3 if the product fails in program-2.
U
SE
R
T
I
P
