Page 15
Test Result Messages
Test result messages in the status box can help when
adjusting test parameters. Repeated P ERR, for instance,
could indicate the need to widen the pressure error
tolerance by increasing the Press. Error value.
Test Results Status
These messages appear at the end of test to tell operators whether a test
passed or why a test was unsuccessful.
PASS The product stayed within all test parameters of each
test that was run.
ABORT
The start button was pressed, ending the test.
P ERR Test pressure was above or below the pressure error
tolerance set in the parameters menu.
GROSS In a pressure decay test, the test pressure fell below
the minimum during stabilization phase.
LEAK In a pressure decay test, the pressure decay exceeded
the reject level setpoint.
OCC In an occlusion test, the pressure decay did not reach
the reject level setpoint
LOW In a flow or burst test, flow or burst was below the
minimum setpoint.
HIGH In a flow or burst test, flow or burst was above the
maximum setpoint.
OVER In a flow test, the pressure was above the maximum
pressure the flow sensor can withstand.
NO In a burst test, Sprint did not detect a large enough
pressure change to detect a burst.
U
SE
R
T
I
P
