SPRINT LC RUN MODE HELP
Run Mode Functions : OVAL
Previuos Pgrm : Hold Up
Next Prgm : Hold Down
Retest : Plus
Abort Test : WHITE SQ.
Help Menu
When the LOCKOUT keyswitch is turned to the program position, the main
setup menu appears. At the bottom of the setup menu is a function
associated with the INCREMENT keypad labeled HELP. The help menu,
shown below, gives setup personnel reminders about the major Sprint LC
run-mode keypad functions. These are features that are available to the
operator.
Next Program
By pressing and holding the up arrow keypad the current program number
is incremented. Release the keypad when the desired program is displayed.
Previous Program
By pressing and holding the down arrow keypad the current program
number is decremented. Release the keypad when the desired program is
displayed.
Re-Test
If Sprint LC says there is a product failure, operators can re-test the
product by pressing the INCREMENT keypad. Re-test works only if the last
test failed. Operators can’t re-test a part that has passed.
Figure 13
