Uson SPRINT LC - Connecting Small Parts

Page 61
Typical connection for a closed product. The coupling port
is capped off. Also used for flow testing through an
open product.
FIGURE 25
Typical connection for an open product when a sealing
fixture is used to close the test circuit. Also used
for combination leak and flow testing.
FIGURE 26
Connecting Small Parts
Small products, such as catheters, can attach directly to a
fitting on the test port.
U
s
o
n
SP
R
I
N
T
L
C
1
2
U
s
o
n
S
P
R
I
N
T
L
C
1
2
U
SE
R
T
I
P
Part to be
tested.
Closed on
back side.
Sealing Fixture to seal
back side of o
p
en
p
art.
