Main Digital Readout
Multi Channel Testers
Multi Channel testers divide the run display into 2, 3 or 4 sections
depending on the number of channels or test ports. They show individual
readings for each channel.
Each of the individual channel displays follow the same format as
described for the single channel testers. They are displayed with a smaller
font but convey the same information.
Two channel Example:
After the end of the test.
Four Channel Example:
During the test time
FIGURE 28
PD 1.2 TEST
Mode Test Time Status
PROGRAM 1
Test Press. Tested Reject
10.000 psig 0 0
Ch1 .005 TEST
Ch2 .008 TEST
Ch3 .006 TEST
Ch4 .005 TEST
PD .0 PASS
Mode Test Time Status
PROGRAM 1
Test Press. Tested Reject
10.000 psig 2 0
Ch1 .008 PASS
Ch2 .006 PASS
