User's Guide ______________________________________________________________________
200 _________________________________________________________________ M211296EN-A
5. The Select File window is displayed as shown in Figure 117 below.
Select the appropriate setup file and click Select File. Note that the
default folder for uploading configuration files is defined in the
AWS Client Options window.
1101-024
Figure 117 Selecting an Upload Configuration File
NOTE
Make sure to select appropriate file for your system; see Table 51 below.
Table 51 AWS330 Setup Alternatives
File Name Description
metawsaa.adc Configuration for system with Ethernet telemetry
metawsba.adc Configuration for system with GSM/GPRS telemetry
mewtawsna.adc Configuration for system with RS232/RS485 serial
links only
