User's Guide ______________________________________________________________________
78 __________________________________________________________________ M211296EN-A
NOTE
The sensor support package includes a bag of tools, screws, and other
useful equipment that you can use for mounting the sensors onto the
sensor support. Keep the bag for later use.
1101-013
Figure 38 Sensor Support Mounted on Mast
The following numbers refer to Figure 38 above:
1 = Sensor support
2 = Foundation
