Appendix C Building and Using a GPI Device
145
6 Slip the switch into the end cap and secure it using the nut
and washer.
7 Solder the other ends of the cable to the plug (
F).
8 Connect to the tip (
G) and the base (H) of the plug. Don’t
connect anything to the middle section of the plug (
X).
9 Push the end caps in place.
After you’ve tested the unit, you can cement the end caps (
A
and
E) into place, if you want.
10 Solder the wires of the other end of the cord to the poles
from the tip and base of the stereo mini-pin plug (
F). If you
aren’t sure which poles are which, ask at the store when you
make the purchase.
11 Plug your new remote trigger plug into the GPI jack on the
Personal TitleMaker rear panel.
USING A GPI TRIGGER DEVICE
If your edit controller is automatic and has GPI trigger, you can trigger
each page in a project with the controller. You might need a special
cable to connect the GPI jacks from the GPI device to Personal Title-
Maker.
WARNING!
Always turn off power before plugging into any GPI
jack.
The following instructions explain how to automatically trigger titles
using the Videonics Thumbs Up device in conjunction with Personal
TitleMaker. Instructions for other devices should be similar, but you
should check the device instructions beforehand.
1 Connect the Thumbs Up device to Personal TitleMaker using
an appropriate cable.
2 As you create pages with Personal TitleMaker, press the “T”
button where you want to trigger the titles. You can trigger
titles between scenes or anywhere in the middle of a scene.
