Watlow F4T User Manual

Watlow F4T • 287 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Measure CJC
"Off (62)
On (63)"
On (63)
"unsigned 16-bit
Access = RW"
"Temperature In 1:
Module 1, 32204
Temperature In 1:
Module 2, 32274
Temperature In 1:
Module 3, 32344
Temperature In 1:
Module 4, 32414
Temperature In 1:
Module 5, 32484
Temperature In 1:
Module 6, 32554"
Ambient Temperature
-99,999.000 to
99,999.000°F or
units, -55,572.778 to
55,537.222°C
"IEEE Float
Access=R"
"Temperature In 1:
Module 1, 32206
Temperature In 1:
Module 2, 32276
Temperature In 1:
Module 3, 32346
Temperature In 1:
Module 4, 32416
Temperature In 1:
Module 5, 32486
Temperature In 1:
Module 6, 32556"
Ambient Offset
-99,999.000 to
99,999.000°F or
units, -55,555.000 to
55,555.000°C
0.0
"IEEE Float
Access=RW"
"Temperature In 1:
Module 1, 32214
Temperature In 1:
Module 2, 32284
Temperature In 1:
Module 3, 32354
Temperature In 1:
Module 4, 32424
Temperature In 1:
Module 5, 32494
Temperature In 1:
Module 6, 32564"
Analog Output (See: p.90)
Output Type
"Volts (104)
Milliamps (112)"
Volts (104)
"unsigned 16-bit
Access = RW"
"Analog Output 1:
Module 1, 32566
Analog Output 1:
Module 2, 32716
Analog Output 1:
Module 3, 32866
Analog Output 1:
Module 4, 33016
Analog Output 1:
Module 5, 33166
Analog Output 1:
Module 6, 33316
Add 50 for the
address of the next
Analog Ouput"

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
