Watlow F4T User Manual

Watlow F4T • 288 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Function
"Off (62)
Analog Input (142)
Current (22)
Cool Power (161)
Heat Power (160)
Power (73)
Linearization (238)
Math (240)
Process Value (241)
Set Point Closed (242)
Set Point Open (243)
Special Function Output
1 (1532)
Special Function Output
2 (1533)
Special Function Output
3 (1534)
Special Function Output
4 (1535)
Variable (245)
Condition (10001)
Encoder (1740)
Profile Number (1779)
Cascade Cool Power
(1795)
Cascade Heat Power
(1794)
Cascade Power (1796)
Cascade Set Point
Closed (1797)
Cascade Set Point Open
(1798)"
Off (62)
"unsigned 16-bit
Access = RW"
"Analog Output 1:
Module 1, 32568
Analog Output 1:
Module 2, 32718
Analog Output 1:
Module 3, 32868
Analog Output 1:
Module 4, 33018
Analog Output 1:
Module 5, 33168
Analog Output 1:
Module 6, 33318
Add 50 for the
address of the next
Analog Ouput"
Output Function
Instance
1 To 250 1
"unsigned 8-bit
Access=RW"
"Analog Output 1:
Module 1, 32572
Analog Output 1:
Module 2, 32722
Analog Output 1:
Module 3, 32872
Analog Output 1:
Module 4, 33022
Analog Output 1:
Module 5, 33172
Analog Output 1:
Module 6, 33322
Add 50 for the
address of the next
Analog Ouput"

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
