Watlow F4T User Manual

Watlow F4T • 289 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Electrical Output
Offset
-99999 To 99999 0.0
"IEEE Float
Access=RW"
"Analog Output 1:
Module 1, 32574
Analog Output 1:
Module 2, 32724
Analog Output 1:
Module 3, 32874
Analog Output 1:
Module 4, 33024
Analog Output 1:
Module 5, 33174
Analog Output 1:
Module 6, 33324
Add 50 for the
address of the next
Analog Ouput"
Electrical Output
Slope
-99999 To 99999 1.0
"IEEE Float
Access=RW"
"Analog Output 1:
Module 1, 32576
Analog Output 1:
Module 2, 32726
Analog Output 1:
Module 3, 32876
Analog Output 1:
Module 4, 33026
Analog Output 1:
Module 5, 33176
Analog Output 1:
Module 6, 33326
Add 50 for the
address of the next
Analog Ouput"
Calibration Offset
-99,999.000 to
99,999.000°F or
units, -55,555.000 to
55,555.000°C
0.0
"IEEE Float
Access=RW"
"Analog Output 1:
Module 1, 32578
Analog Output 1:
Module 2, 32728
Analog Output 1:
Module 3, 32878
Analog Output 1:
Module 4, 33028
Analog Output 1:
Module 5, 33178
Analog Output 1:
Module 6, 33328
Add 50 for the
address of the next
Analog Ouput"
Calibration Slope -99999 To 99999 1.0
"IEEE Float
Access=RW"
"Analog Output 1:
Module 1, 32580
Analog Output 1:
Module 2, 32730
Analog Output 1:
Module 3, 32880
Analog Output 1:
Module 4, 33030
Analog Output 1:
Module 5, 33180
Analog Output 1:
Module 6, 33330
Add 50 for the
address of the next
Analog Ouput"

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
