Watlow F4T User Manual

Watlow F4T • 290 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Scale Low -100 To 100 0.0
"IEEE Float
Access=RW"
"Analog Output 1:
Module 1, 32582
Analog Output 1:
Module 2, 32732
Analog Output 1:
Module 3, 32882
Analog Output 1:
Module 4, 33032
Analog Output 1:
Module 5, 33182
Analog Output 1:
Module 6, 33332
Add 50 for the
address of the next
Analog Ouput"
Scale High -100 To 100 10.0
"IEEE Float
Access=RW"
"Analog Output 1:
Module 1, 32584
Analog Output 1:
Module 2, 32734
Analog Output 1:
Module 3, 32884
Analog Output 1:
Module 4, 33034
Analog Output 1:
Module 5, 33184
Analog Output 1:
Module 6, 33334
Add 50 for the
address of the next
Analog Ouput"
Range Low
-99,999.000 to
99,999.000°F or
units, -55,555.000 to
55,555.000°C
0.0
"IEEE Float
Access=RW"
"Analog Output 1:
Module 1, 32586
Analog Output 1:
Module 2, 32736
Analog Output 1:
Module 3, 32886
Analog Output 1:
Module 4, 33036
Analog Output 1:
Module 5, 33186
Analog Output 1:
Module 6, 33336
Add 50 for the
address of the next
Analog Ouput"
Range High
-99,999.000 to
99,999.000°F or
units, -55,555.000 to
55,555.000°C
100.0
"IEEE Float
Access=RW"
"Analog Output 1:
Module 1, 32588
Analog Output 1:
Module 2, 32738
Analog Output 1:
Module 3, 32888
Analog Output 1:
Module 4, 33038
Analog Output 1:
Module 5, 33188
Analog Output 1:
Module 6, 33338
Add 50 for the
address of the next
Analog Ouput"

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
