Watlow F4T • 291 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Analog Output
Electrical Value
"IEEE Float
Access=R"
"Analog Output 1:
Module 1, 32596
Analog Output 1:
Module 2, 32746
Analog Output 1:
Module 3, 32896
Analog Output 1:
Module 4, 33046
Analog Output 1:
Module 5, 33196
Analog Output 1:
Module 6, 33346
Add 50 for the
address of the next
Analog Ouput"
Analog Output Control
Operation
"Electrical (1276)
Counts (1037)"
Electrical (1276)
"unsigned 16-bit
Access = RW"
"Analog Output 1:
Module 1, 32598
Analog Output 1:
Module 2, 32748
Analog Output 1:
Module 3, 32898
Analog Output 1:
Module 4, 33048
Analog Output 1:
Module 5, 33198
Analog Output 1:
Module 6, 33348
Add 50 for the
address of the next
Analog Ouput"
Source Value A
"IEEE Float
Access=R"
"Analog Output 1:
Module 1, 32600
Analog Output 1:
Module 2, 32750
Analog Output 1:
Module 3, 32900
Analog Output 1:
Module 4, 33050
Analog Output 1:
Module 5, 33200
Analog Output 1:
Module 6, 33350
Add 50 for the
address of the next
Analog Ouput"
Output Type
"2 (1)
3 (2)"
"unsigned 16-bit
Access = R"
"Analog Output 1:
Module 1, 32614
Analog Output 1:
Module 2, 32764
Analog Output 1:
Module 3, 32914
Analog Output 1:
Module 4, 33064
Analog Output 1:
Module 5, 33214
Analog Output 1:
Module 6, 33364
Add 50 for the
address of the next
Analog Ouput"

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
