Watlow F4T User Manual

Watlow F4T • 292 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Discrete Input (See:
p.130)
Input Type
"Input Voltage (193)
Input Dry Contact (44)"
Input Dry Contact (44)
"unsigned 16-bit
Access = RW"
"Digital Input 2:
Module 1, 33466
Digital Input 2: Module
2, 33506
Digital Input 2: Module
3, 33546
Digital Input 2: Module
4, 33586
Digital Input 2: Module
5, 33626
Digital Input 2: Module
6, 33666"
Input State
"On (63)
Off (62)"
"unsigned 16-bit
Access = R"
"Digital Input 2:
Module 1, 33486
Digital Input 2: Module
2, 33526
Digital Input 2: Module
3, 33566
Digital Input 2: Module
4, 33606
Digital Input 2: Module
5, 33646
Digital Input 2: Module
6, 33686"
Error
"None (61)
Open (65)
Shorted (127)
Measurement Error (140)
Bad Calibration Data
(139)
Ambient Error (9)
RTD Error (141)
Fail (32)
Math Error (1423)
Not Sourced (246)
Stale (1617)"
"unsigned 16-bit
Access = R"
"Digital Input 2:
Module 1, 33500
Digital Input 2: Module
2, 33540
Digital Input 2: Module
3, 33580
Digital Input 2: Module
4, 33620
Digital Input 2: Module
5, 33660
Digital Input 2: Module
6, 33700"
Discrete Input / Output (See: p.131)
Direction
"Output (68)
Input Voltage (193)
Input Dry Contact (44)"
Output (68)
"unsigned 16-bit
Access = RW"
"Digital I/O 1: Module
1, 33706
Digital I/O 1: Module
2, 33946
Digital I/O 1: Module
3, 34186
Digital I/O 1: Module
4, 34426
Digital I/O 1: Module
5, 34666
Digital I/O 1: Module
6, 34906
Add 40 for the
address of the next
output"

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
