Watlow F4T User Manual

Watlow F4T • 293 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Time Base Type
"Fixed Time Base (34)
Variable Time Base
(103)"
Fixed Time Base (34)
"unsigned 16-bit
Access = RW"
"Digital I/O 1: Module
1, 33708
Digital I/O 1: Module
2, 33948
Digital I/O 1: Module
3, 34188
Digital I/O 1: Module
4, 34428
Digital I/O 1: Module
5, 34668
Digital I/O 1: Module
6, 34908
Add 40 for the
address of the next
output"
Fixed Time Base .1 To 60 1
"IEEE Float
Access=RW"
"Digital I/O 1: Module
1, 33710
Digital I/O 1: Module
2, 33950
Digital I/O 1: Module
3, 34190
Digital I/O 1: Module
4, 34430
Digital I/O 1: Module
5, 34670
Digital I/O 1: Module
6, 34910
Add 40 for the
address of the next
output"
AC Line Frequency
"50 Hz (3)
60 Hz (4)"
"unsigned 16-bit
Access = RW"
"Digital I/O 1: Module
1, 33712
Digital I/O 1: Module
2, 33952
Digital I/O 1: Module
3, 34192
Digital I/O 1: Module
4, 34432
Digital I/O 1: Module
5, 34672
Digital I/O 1: Module
6, 34912
Add 40 for the
address of the next
output"

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
