Watlow F4T 295 Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Output Function
Instance
1 To 250 1
"unsigned 8-bit
Access=RW"
"Digital I/O 1: Module
1, 33716
Digital I/O 1: Module
2, 33956
Digital I/O 1: Module
3, 34196
Digital I/O 1: Module
4, 34436
Digital I/O 1: Module
5, 34676
Digital I/O 1: Module
6, 34916
Add 40 for the
address of the next
output"
Output State
"On (63)
Off (62)"
"unsigned 16-bit
Access = R"
"Digital I/O 1: Module
1, 33718
Digital I/O 1: Module
2, 33958
Digital I/O 1: Module
3, 34198
Digital I/O 1: Module
4, 34438
Digital I/O 1: Module
5, 34678
Digital I/O 1: Module
6, 34918
Add 40 for the
address of the next
output"
Output Power 0 to 100%
"IEEE Float
Access=R"
"Digital I/O 1: Module
1, 33720
Digital I/O 1: Module
2, 33960
Digital I/O 1: Module
3, 34200
Digital I/O 1: Module
4, 34440
Digital I/O 1: Module
5, 34680
Digital I/O 1: Module
6, 34920
Add 40 for the
address of the next
output"
Low Power Scale 0 To 100 0.0
"IEEE Float
Access=RW"
"Digital I/O 1: Module
1, 33722
Digital I/O 1: Module
2, 33962
Digital I/O 1: Module
3, 34202
Digital I/O 1: Module
4, 34442
Digital I/O 1: Module
5, 34682
Digital I/O 1: Module
6, 34922
Add 40 for the
address of the next
output"
