Watlow F4T User Manual

Watlow F4T • 297 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Error
"None (61)
Open (65)
Shorted (127)
Measurement Error (140)
Bad Calibration Data
(139)
Ambient Error (9)
RTD Error (141)
Fail (32)
Math Error (1423)
Not Sourced (246)
Stale (1617)"
"unsigned 16-bit
Access = R"
"Digital I/O 1: Module
1, 33740
Digital I/O 1: Module
2, 33980
Digital I/O 1: Module
3, 34220
Digital I/O 1: Module
4, 34460
Digital I/O 1: Module
5, 34700
Digital I/O 1: Module
6, 34940
Add 40 for the
address of the next
output"
Discrete Output, Solid-State Relay and Switched DC/Open Collector (See: p.134)
Time Base Type
"Fixed Time Base (34)
Variable Time Base
(103)"
Fixed Time Base (34)
"unsigned 16-bit
Access = RW"
"Output 1: Module 1,
35148
Output 1: Module 2,
35308
Output 1: Module 3,
35468
Output 1: Module 4,
35628
Output 1: Module 5,
35788
Output 1: Module 6,
35948
Add 40 for the
address of the next
output"
Fixed Time Base .1 To 60 1
"IEEE Float
Access=RW"
"Output 1: Module 1,
35150
Output 1: Module 2,
35310
Output 1: Module 3,
35470
Output 1: Module 4,
35630
Output 1: Module 5,
35790
Output 1: Module 6,
35950
Add 40 for the
address of the next
output"

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
