Watlow F4T User Manual

Watlow F4T • 304 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Fixed Time Base 5 To 60 20
"IEEE Float
Access=RW"
"Output 1: Module 1,
36590
Output 1: Module 2,
36750
Output 1: Module 3,
36910
Output 1: Module 4,
37070
Output 1: Module 5,
37230
Output 1: Module 6,
37390
Add 40 for the
address of the next
output"

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
