Watlow F4T User Manual

Watlow F4T • 303 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Error
"None (61)
Open (65)
Shorted (127)
Measurement Error (140)
Bad Calibration Data
(139)
Ambient Error (9)
RTD Error (141)
Fail (32)
Math Error (1423)
Not Sourced (246)
Stale (1617)"
"unsigned 16-bit
Access = R"
"Limit Output 1:
Module 1, 36134
Limit Output 1:
Module 2, 36214
Limit Output 1:
Module 3, 36294
Limit Output 1:
Module 4, 36374
Limit Output 1:
Module 5, 36454
Limit Output 1:
Module 6, 36534
Add 40 for the
address of the next
Output"
Output Type
"Form A Mechanical
Relay (10029)
Form C Mechanical
Relay (10028)"
"unsigned 16-bit
Access = R"
"Limit Output 1:
Module 1, 36144
Limit Output 1:
Module 2, 36224
Limit Output 1:
Module 3, 36304
Limit Output 1:
Module 4, 36384
Limit Output 1:
Module 5, 36464
Limit Output 1:
Module 6, 36544
Add 40 for the
address of the next
Output"
Discrete Output, Electromechanical Relay (See: p.128)
Time Base Type Fixed Time Base (34) Fixed Time Base (34)
"unsigned 16-bit
Access = RW"
"Output 1: Module 1,
36588
Output 1: Module 2,
36748
Output 1: Module 3,
36908
Output 1: Module 4,
37068
Output 1: Module 5,
37228
Output 1: Module 6,
37388
Add 40 for the
address of the next
output"

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
