Watlow F4T • 302 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Discrete Output, Limit (See:
p.140)
Function Limit (126) Limit (126)
"unsigned 16-bit
Access = RW"
"Limit Output 1:
Module 1, 36114
Limit Output 1:
Module 2, 36194
Limit Output 1:
Module 3, 36274
Limit Output 1:
Module 4, 36354
Limit Output 1:
Module 5, 36434
Limit Output 1:
Module 6, 36514
Add 40 for the
address of the next
Output"
Output State
"On (63)
Off (62)"
"unsigned 16-bit
Access = R"
"Limit Output 1:
Module 1, 36118
Limit Output 1:
Module 2, 36198
Limit Output 1:
Module 3, 36278
Limit Output 1:
Module 4, 36358
Limit Output 1:
Module 5, 36438
Limit Output 1:
Module 6, 36518
Add 40 for the
address of the next
Output"
Source Value A 0 or 100
"IEEE Float
Access=R"
"Limit Output 1:
Module 1, 36130
Limit Output 1:
Module 2, 36210
Limit Output 1:
Module 3, 36290
Limit Output 1:
Module 4, 36370
Limit Output 1:
Module 5, 36450
Limit Output 1:
Module 6, 36530
Add 40 for the
address of the next
Output"

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
