Watlow F4T 301 Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
High Power Scale 0 To 100 100.0
"IEEE Float
Access=RW"
"Output 1: Module 1,
35164
Output 1: Module 2,
35324
Output 1: Module 3,
35484
Output 1: Module 4,
35644
Output 1: Module 5,
35804
Output 1: Module 6,
35964
Add 40 for the
address of the next
output"
Source Value A
-99,999.000 to
99,999.000°F or
units, -55,555.000 to
55,555.000°C
"IEEE Float
Access=R"
"Output 1: Module 1,
35170
Output 1: Module 2,
35330
Output 1: Module 3,
35490
Output 1: Module 4,
35650
Output 1: Module 5,
35810
Output 1: Module 6,
35970
Add 40 for the
address of the next
output"
Error
"None (61)
Open (65)
Shorted (127)
Measurement Error (140)
Bad Calibration Data
(139)
Ambient Error (9)
RTD Error (141)
Fail (32)
Math Error (1423)
Not Sourced (246)
Stale (1617)"
"unsigned 16-bit
Access = R"
"Output 1: Module 1,
35174
Output 1: Module 2,
35334
Output 1: Module 3,
35494
Output 1: Module 4,
35654
Output 1: Module 5,
35814
Output 1: Module 6,
35974
Add 40 for the
address of the next
output"
Output Type
"SSR (10034)
SSR w/ Shared Common
(10035)
Switched DC (10033)
Switched DC / Open
Collector (10032)"
"unsigned 16-bit
Access = R"
"Output 1: Module 1,
35184
Output 1: Module 2,
35344
Output 1: Module 3,
35504
Output 1: Module 4,
35664
Output 1: Module 5,
35824
Output 1: Module 6,
35984
Add 40 for the
address of the next
output"
