Watlow F4T User Manual

Watlow F4T • 300 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Output Function
Instance
1 To 250 1
"unsigned 8-bit
Access=RW"
"Output 1: Module 1,
35156
Output 1: Module 2,
35316
Output 1: Module 3,
35476
Output 1: Module 4,
35636
Output 1: Module 5,
35796
Output 1: Module 6,
35956
Add 40 for the
address of the next
output"
Output State
"On (63)
Off (62)"
"unsigned 16-bit
Access = R"
"Output 1: Module 1,
35158
Output 1: Module 2,
35318
Output 1: Module 3,
35478
Output 1: Module 4,
35638
Output 1: Module 5,
35798
Output 1: Module 6,
35958
Add 40 for the
address of the next
output"
Output Power 0 to 100%
"IEEE Float
Access=R"
"Output 1: Module 1,
35160
Output 1: Module 2,
35320
Output 1: Module 3,
35480
Output 1: Module 4,
35640
Output 1: Module 5,
35800
Output 1: Module 6,
35960
Add 40 for the
address of the next
output"
Low Power Scale 0 To 100 0.0
"IEEE Float
Access=RW"
"Output 1: Module 1,
35162
Output 1: Module 2,
35322
Output 1: Module 3,
35482
Output 1: Module 4,
35642
Output 1: Module 5,
35802
Output 1: Module 6,
35962
Add 40 for the
address of the next
output"

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
