Watlow F4T • 299 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Function
"Off (62)
Analog Input (142)
Alarm (6)
Cool Power (161)
Heat Power (160)
Compare (230)
Counter (231)
Digital I/O (1142)
Profile Event Out A
(233)
Profile Event Out B
(234)
Profile Event Out C
(235)
Profile Event Out D
(236)
Profile Event Out E
(247)
Profile Event Out F
(248)
Profile Event Out G
(249)
Profile Event Out H
(250)
Function Key (1001)
Logic (239)
Linearization (238)
Math (240)
Process Value (241)
Special Function Output
1 (1532)
Special Function Output
2 (1533)
Special Function Output
3 (1534)
Special Function Output
4 (1535)
Timer (244)
Variable (245)
Limit (126)
Condition (10001)
Encoder (1740)
Profile Number (1779)
Profile Running (1780)
Profile Paused (1781)
Cascade Cool Power
(1795)
Cascade Heat Power
(1794)"
Off (62)
"unsigned 16-bit
Access = RW"
"Output 1: Module 1,
35154
Output 1: Module 2,
35314
Output 1: Module 3,
35474
Output 1: Module 4,
35634
Output 1: Module 5,
35794
Output 1: Module 6,
35954
Add 40 for the
address of the next
output"

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
