Watlow F4T User Manual

Watlow F4T • 306 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Output Function
Instance
1 To 250 1
"unsigned 8-bit
Access=RW"
"Output 1: Module 1,
36596
Output 1: Module 2,
36756
Output 1: Module 3,
36916
Output 1: Module 4,
37076
Output 1: Module 5,
37236
Output 1: Module 6,
37396
Add 40 for the
address of the next
output"
Output State
"On (63)
Off (62)"
"unsigned 16-bit
Access = R"
"Output 1: Module 1,
36598
Output 1: Module 2,
36758
Output 1: Module 3,
36918
Output 1: Module 4,
37078
Output 1: Module 5,
37238
Output 1: Module 6,
37398
Add 40 for the
address of the next
output"
Output Power
"IEEE Float
Access=R"
"Output 1: Module 1,
36600
Output 1: Module 2,
36760
Output 1: Module 3,
36920
Output 1: Module 4,
37080
Output 1: Module 5,
37240
Output 1: Module 6,
37400
Add 40 for the
address of the next
output"
Low Power Scale 0 To 100 0.0
"IEEE Float
Access=RW"
"Output 1: Module 1,
36602
Output 1: Module 2,
36762
Output 1: Module 3,
36922
Output 1: Module 4,
37082
Output 1: Module 5,
37242
Output 1: Module 6,
37402
Add 40 for the
address of the next
output"

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
