Watlow F4T • 312 • Chapter 6 Appendix
Data Logging
• User selectable parameters: Up to a maximum of 128 active parameters depending
on configuration
• Logging interval: Programmable increments between 0.1 seconds and 60 minutes if
logging to internal memory. Logging directly to USB; 1.0 seconds to 60 minutes
• File types: .CSV for standard data logging or proprietary format for encrypted data
log option
• Storage: 80MB internal memory or to USB memory stick
• File transfer: Internal memory to USB host port or to Ethernet Modbus
®
TCP
• Transfer options: On demand by user or user programmable based on when a new
data log file record is available. Utilizes TFTP and Samba protocols
• Record: Date and time stamped
Batch Processing
• Compatible with many bar code types including Code 128, Code 39, Extended Code
39, Data Matrix, Interleaved 2 of 5, ISSN, SISAC, LOGMARS, QR, UCC/EAN-128
(GS1-128, UPC-A & E)
• Compatible with most USB scanner types such as Zebra DS4308, DS2208, LI2208 and
LS2208
• USB port provides 500mA max. power supply for bar code scanner/base charging
• Display can show bar code fields up to a maximum length of 48 characters.
Characters might wrap to 2 rows after 24 characters
• Part-Profile list entries – approximately 1,000 typical length part numbers of 15
characters each can be stored. Can easily import
different part files via USB thumb
drive connection to cover a higher quantity range of part lists
• Program the bar code scanner to add an enter key (carriage return feed) at the end
of each bar code data field sent to F4T/D4T. Refer to USB scanner user manual.
Trending
• 4 user programmable charts
• 6 pens available per chart
• View analog sensors, process values, set points and power
Number of Function Blocks by Ordering Option
Function Block Basic Set 1 Set 2
Alarm 6 8 14
Compare None 4 16
Counter None 4 16
Linearization 4 4 8
Logic None 12 24
Math None 12 24
Process Value 4 4 8
Special Output Function
(including compressor)
None 2 4
Timer None 6 16
Variable 4 12 24

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
