Watlow F4T User Manual

Watlow F4T • 325 • Chapter 6 Appendix
Flex Module - Communications Ordering Information
Part Number
① ② ③
Module
ID Type
④
Future
Option
-
⑤
Comm.
Option
⑥ ⑦ ⑧
Future
Option
-
⑨
Future
Options
⑩
Custom
Options and
Connectors
⑪ d
Custom Options - Firmware,
Overlay, Preset Parameters,
Locked Code
FM C A 2 A A
⑤ Communication Option
2 = Modbus
®
RTU 232/485*
⑩ Custom Options and Connectors
A = Right angle screw connector (standard)
F = Front screw connector
⑪ d Custom Options - Firmware, Overlay,
Preset Parameters, Locked Code
AA = Standard with quick start guide
AB = Standard without quick start guide
AC = Replacement connectors hardware only - for the
entered model number
XX = Custom

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
