Watlow F4T Controller • 30 • Chapter 2 Configuration Using Composer
Note:
If using Asian fonts, you may need to create a user, and password, using the Latin
character set.
- Samba Path: shared directory path and name.
Note:
If using Asian fonts in the path name, please try using latin characters, or numbers
as your folder name, and share name.
- Remote IP Address: the IP address of the remote computer.
- Remote Host Name: the name of the remote computer.
- Transfer Progress: when a transfer is initiated this will reflect its progress from 0% to
100%.
Note:
If an error were to occur, as described below, this value could exceed 100.
- Transfer Results, will return the enumerated values shown below:
Blank Nothing to report
• Not configured, no activ-
ity.
• Transfer not initiated.
- - - -
No Files to Transfer
No data log files in in-
ternal memory
• Data logging has not yet
been started.
• Files have already been
moved from internal
memory.
- - - -
Transfer Complete
All data log files have
been moved from inter-
nal memory
• File transfer initiated and
completed successfully.
- - - -
Transferring Files
Data log files being
moved from internal
memory
• File transfer initiated and
in progress.
- - - -
Server Down
Connectivity from client
to server not present
• Server not present.
• Server not configured or
configured incorrectly.
Samba
• Check and ensure user account info
(name and password) is correct.
• Check and ensure that the shared
folder name is correct and shared
with the user account mentioned
above.
TFTP
• Ensure server is running and config-
ured for read/write capability.
Need Host IP IP address not present
• No connectivity between
PC and F4T.
• Incorrect IP address en-
tered.
TFTP
• Verify a physical connection between
PC and F4T.
• Check the controller IP address from
the F4T front panel: push Main Menu >
Settings > Network > Ethernet.
• Ping the F4T to verify its presence on
the network.
