Operation 72800115 Markoprint X4JET
Seite 102 von 177 GB
Sensor Input
In this menu the used sensor can be adjusted. Following settings are possible:
Sensor 1+2
Sensor 1+2 inverse
Sensor 3+4
Sensor 3+4 inverse
There are 2 sensor inputs „Sensor 1+2“ and „Sensor 3+4“. Standard is Pin 4 for the
output of the sensor. Some sensors send the inverse signal on Pin 2. This can be used
with the parameter Sensor 1+2 invers“.
Chapter Sensor, Page 144
1. Touch the iLOGIK once in one of the status menus.
The Label submenu is displayed.
2. Call the System submenu by rotating the iLOGIK and select by pressing.
The Date/Time submenu is displayed.
3. Call the Sensor input submenu by rotating the iLOGIK and select it by pressing.
