Installation and initial operation 72800115 Markoprint X4JET
Seite 68 von 177 GB
Compact mounting bracket
The Multiline MX Compact mounting bracket is used to install the print head in the
Compact model. The print head and ink system are consolidated into a single unit.
Fig. 35: Mounting bracket Compact
The service unit is mounted on the lower leg of the mounting bracket.
Optionally, it can be mounted directly at the transport belt or on a separate floor support.
Ensure that the service unit is lower than the print head so that no ink can run back to
the head.
