Technical data 72800115 Markoprint X4JET
Seite 19 von 177 GB
Technical data
General specifications
Specification*
Value
Unit
Weight
3400
g
Length
230
mm
Width
220
mm
Height ahead
42
mm
Height behind
140
mm
*all specifications excl. bracket and connections
Connection parameters
Electrical
Specification
Value
Unit
Voltage (Device)
90 to 240
V AC
Frequency (Power pack)
50 to 60
Hz
Current consumption,
maximum
0,5
A
Power consumption,
maximum
100
W
Protection class
IP 40
-
Standby power input
<18
W
Data interfaces
Specification
Description
USB
USB A
USB
USB B
Ethernet
RJ45
RS 232
Sub-D 9-Pol male
Connection
Voltage
Max. flow
Sensor
24V ±10%
< 100mA
Encoder
24V ±10%
< 100mA
USB
5V ±10%
< 100mA
