Weber Markoprint X4JET - Alarm Light

Appendix 72800115 Markoprint X4JET
Seite 147 von 177 GB
Alarm light
The alarm light (24V) will be connected to the 8-pole M12-socket.
24V voltage will be switched on the outputs.
PIN
Color
Function
1 – Out1
White
Alarm red lamp
2 – Out2
Brown
Warning orange lamp
3 – Out3
Green
OK green lamp
4 – Out4
Yellow
Reserve
5 – In 7
Reserve
6 – In 8
Reserve
7 - +24V
Power max. 100mA
8 - GND
Red
common contact
