Disassembly 72800115 Markoprint X4JET
Seite 125 von 177 GB
Disassembly may only be performed by specially trained specialized staff.
Work on the electrical system may only be performed by electricians.
Disassembly of a MX print head
Material damage due to incorrect disposal!
Electronic components are destroyed if allowed to come
into contact with escaping ink.
Therefore:
– Close the ink systems before disposal carefully.
Instruction
Please disassemble the MX print head as follows:
Switch off the control system.
Isolate maintenance station or main adaptor from the print head.
Close the print head with the cleaned locking clamp.
Check whether the red sealing ring (o-ring) is present.
Place the red sealing ring into the opening of the ink container and close it
with the screw cap.
Close ventilation opening with the plastic cap.
Disassemble the system and pack it carefully.
To prevent damage during transportation, choose a box with adequate padding.
Leave a gap of at least 5cm between unit and box for filling with absorbent and
impact-absorbing filling.
Please do not pack unit in plastic bag.
Because any escaped ink cannot be soaked up, it spreads over the whole unit
causing damage.
The resulting damage and cleaning overhead unnecessarily increase repair costs.
For best possible transportation, original packaging is available from Weber
Marking Systems for this system.
