Weber Markoprint X4JET - Table of faults

Faults 72800115 Markoprint X4JET
Seite 115 von 177 GB
Table of faults
Controller
Disorder
Possible cause
Troubleshooting
Recovered by
Controller
does not
start
No power supply
Check power supply
Electrician
No screen
display
No signal from the system
Start the system
Instructed
person
Print head
does not
produce a
print
No start pulse
Check photocell and
connection cable
Electrician
Print parameter incorrect
Check print parameter,
adjust if necessary
Instructed
person
Fault in the electronics of
the controller or the print
head
Send controller or print
head in for repairs
Manufacturer
Faulty rotary encoder or
incorrect rotary encoder
settings
Check rotary encoder
and encoder settings
Instructed
person
HP print head
Disorder
Possible cause
Troubleshooting
Recovered by
The print
head does
not print
at all
No start pulse
Check photo sensor
connection
Electrician
Print parameter incorrect
Check print parameter,
adjust if necessary
Instructed
person
Fault in the electronics of the
print head
Send print head in for
repair
Manufacturer
Faulty rotary encoder or
incorrect rotary encoder
settings
Check rotary encoder
and encoder settings
Instructed
person
Bad and
fuzzy print
The distance between print
head and product is too big
Reduce distance to 0 -3
mm
Qualified
person
Low intensity
Increase intensity
Instructed
person
Empty ink cartridge
Change ink cartridge
Instructed
person
Blocked nozzles
Spitting and wipe the
nozzle plate if
necessary
Instructed
person
