Weber Markoprint X4JET - Serial Interface RS232

Appendix 72800115 Markoprint X4JET
Seite 156 von 177 GB
Serial Interface RS232
Connection 9-pole Sub-D-connector.
PIN
Name
Description
Abbreviation
In/Out
1
NC
2
Transmit Data
Cable for transmitted data
TxD
Out
3
Receive Data
Cable for data reception
RxD
In
4
NC
5
Ground
Signal ground. The signal ground
will be measured against the
cable.
GND
-
6
NC
7
NC
8
NC
9
NC
-
Common Ground
Common ground (not data
ground)
-
-
