Indicator lights
Indicator lights on the controller
LED’s, which light up in different colours according to the operating mode, are located on
the right and underneath the display. The LED’s for status sensor and network are
characterized with symbols.
The meaning of the different coloured messages is explained in the table below.
Fig. 38: Indicator lights
No.
Description
1
STATUS SENSOR 1 & 2
2
STATUS SENSOR 3 & 4
3
NETWORK
4
STATUS PRINT HEAD 1 TO 4
5
SELECTION PRINT HEAD MODULE
1
2
3
4
5
