Installation and initial operation 72800115 Markoprint X4JET
Seite 60 von 177 GB
Inserting / remove the HP ink cartridge
With the printing process switched on, a print head electronics fault may arise.
Therefore:
Replace the cartridge only when the printing process is switched off.
Inserting the ink cartridge:
1. Remove the protective foil from the nozzle plate.
Use the ink cartridge as soon as possible after having removed the protective foil.
2. Before replacement of the cartridge, wipe the nozzle plate once with a lint-free cloth.
3. Insert the ink cartridge in the cartridge holder as illustrated.
Fig. 26: Insert HP ink cartridge
4. Click the ink cartridge by lightly pressure at the end.
Fig. 27: Fix HP ink cartridge
If a new ink cartridge is inserted, the cartridge counters must be reset.
Chapter Reset ink counter, Page 97
The correct place of an ink cartridge is also shown on the display below status
menu 1.
Fig. 28: Display change with correct inserted cartridge
Remove the HP ink cartridge from the print head:
1. Press diagonal upwards at the end of cartridge.
